China Deutz Engine XY-2B Soil and Rock Core Drilling Rig for Minerals Exploration With 50-500 m and NQ

China Deutz Engine XY-2B Soil and Rock Core Drilling Rig for Minerals Exploration With 50-500 m and NQ

China Deutz Engine XY-2B Soil and Rock Core Drilling Rig for Minerals Exploration With 50-500 m and NQ

Detail produk:

Tempat asal: Chongqing
Sertifikasi: ISO9001-2008
Nomor model: XY-2B

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order: 1 set
Harga: 1-12000USD/set
Kemasan rincian: Kotak polikayu
Waktu pengiriman: Penuh
Syarat-syarat pembayaran: T/t atau l/c
Menyediakan kemampuan: 1000 set/tahun
Hubungi sekarang
Detil Deskripsi produk
Jenis: rig spindel Jenis mesin: Peralatan pengeboran
Bahan: Baja karbon Jenis pemrosesan: Penempaan
Menggunakan: Penambangan Bijih Warna: Merah atau Kuning
Torsi: 3300 nm Kecepatan putar: 8 ke depan, 2 terbalik
Satuan daya: Deutz F4L912 atau 4100, 30 kW Berat: 1200 kg tidak termasuk unit daya
Dimensi: 2220*900*1880 mm

                                                        XY-2B  Portable Core Drilling Rig

                               ADD: NO.1 Kuaileli, Xiaolongkan Street, Shapingba District, Chongqing China;
                                      Skype: lucyfang9 ; Website: www.lucydrillingrig.com email: lucyfang15@yahoo.com;
                                    M: +86-13628481197 TEL.:+86-15111813754 ; +86-15923510719



Applications:

     XY-2B drill rig derived from XY-2 drill rig, it not only keeps all performances of XY-2 drill, but also adds spindle inner hole diameter to 96mm. It is mainly used in shallow and medium deep diamond and tungsten carbide core drilling, can also be used in geotechnical, hydro-geological, water well and mini-pile grouting hole drilling.It is especially suitable for constructions of hydroelectric power station, highway, railroad and harbor etc. In common with XY-2 drill in all design but hydraulic chuck and rotary head modified.



Technical Specifications




Drilling capacity (m)

AW rod

530 m

BW rod

420 m

NW rod

320 m

AQ rod

565 m

BQ rod

460 m

NQ rod

350 m

HQ rod

250-300 m

Φ73 rod

100 m

Φ60 rod

200 m

Φ50 rod

380 m

Φ42 rod

530 m


Spindle speed(r/min)

Forward

57;99;157;217;270;470;742;1024

 Reverse

45;212


Max torque(Nm)

3200


Angle range

0-90°


Spindle max pulling/pushing force(KN)

60/45


Spindle stroke (mm)

560


Hoist max lift capacity with single rope (KN)

30


Spindle inner dia. (mm)

96


Oil pump

CBK1020/8


Power unit


Electric motor

Y180L-4,22Kw


Diesel engine

395K2,19.85Kw


Overall dimension(L*W*H) mm

2220×900×1880


Drill weight(excluding power)(kg)

1200



China Deutz Engine XY-2B Soil and Rock Core Drilling Rig for Minerals Exploration With 50-500 m and NQ

China Deutz Engine XY-2B Soil and Rock Core Drilling Rig for Minerals Exploration With 50-500 m and NQ

China Deutz Engine XY-2B Soil and Rock Core Drilling Rig for Minerals Exploration With 50-500 m and NQ



China Deutz Engine XY-2B Soil and Rock Core Drilling Rig for Minerals Exploration With 50-500 m and NQ
